Epson EB-L690SU WUXGA 3LCD Laser Projector 6200 Lumens
Taxes included.
Shipping calculated at checkout.
Standard delivery within 2–5 business days
This product is not available for purchase online. Please call to enquire.
Epson EB-L690SU WUXGA 3LCD Laser Projector 6200 Lumens
The Epson EB-L690SU is a high-performance 3LCD laser projector engineered for professional business and education environments. Delivering 6,200 ANSI lumens of brightness with native WUXGA (1920×1200) resolution, this projector provides exceptional image quality and reliability for demanding applications.
Key Features
- 6,200 ANSI Lumens – Outstanding brightness for large venues and well-lit environments
- WUXGA (1920×1200) Resolution – Crystal-clear, detailed images with 16:10 aspect ratio
- 3LCD Technology – Accurate colour reproduction with equal white and colour brightness
- Laser Light Source – Up to 20,000 hours of virtually maintenance-free operation
- Flexible Installation – 360° projection with motorized lens shift, zoom, and focus
- HDBaseT & HDMI – Versatile connectivity for modern AV systems
Technical Specifications
| Specification | Details |
|---|---|
| Model | EB-L690SU |
| Brightness | 6,200 ANSI Lumens (White/Colour) |
| Resolution | WUXGA (1920×1200) |
| Aspect Ratio | 16:10 |
| Contrast Ratio | 2,500,000:1 |
| Display Technology | 3LCD, 3-chip technology |
| Light Source | Laser diode |
| Light Source Life | Up to 20,000 hours |
| Colour Reproduction | Up to 1.07 billion colours |
| Lens Shift | Vertical: ±67%, Horizontal: ±30% (Motorized) |
| Zoom Ratio | 1.0 - 2.1 (Optical, Motorized) |
| Throw Ratio | 1.35 - 2.84:1 |
| Projection Size | 50" - 500" (1.27m - 12.7m diagonal) |
| Keystone Correction | Vertical: ±30°, Horizontal: ±30° |
| Inputs | HDMI (2x), HDBaseT, VGA, USB-A, RS-232C |
| Network | RJ45 (100Base-TX/10Base-T), Wi-Fi (optional) |
| Audio | 16W mono speaker |
| Noise Level | 35 dB (Normal), 28 dB (Eco) |
| Power Consumption | 545W (Normal), 395W (Eco) |
| Standby Power | 0.5W (Communication On), 0.27W (Communication Off) |
| Dimensions (W×D×H) | 499 × 440 × 163 mm (without feet) |
| Weight | Approx. 13.7 kg |
| Operating Temperature | 0°C - 50°C |
| Operating Humidity | 20% - 80% (non-condensing) |
| Warranty | 3 years or 10,000 hours |
