Yamaha C 5000 Stereo Pre-Amplifier

In pursuit of the intangible musical quality that breathes life into high-fidelity audio, the world's largest sound company presents the C-5000 pre-amplifier. From the concert stage to the home, Yamaha has drawn on its vast musical history to create an instrument capable of faithfully reproducing every nuance and emotion in the performance.

Features

Perfectly balanced signal transmission
Floating balanced pre-amp
Symmetrical, folding-book circuit design
Low-impedance design
Rigid and precise design
Dual Toroidal Transformer
Perfectly Balanced
Together with the GT-5000 turntable and M-5000 power amplifier, Yamaha delivers an end-to-end balanced signal chain across its flagship models for premier performance.

Perfectly Balanced

Together with the GT-5000 turntable and M-5000 power amplifier, Yamaha delivers an end-to-end balanced signal chain across its flagship models for premier performance.

Floating and Balanced Pre-amplifier

The C-5000 features fully balanced and discrete circuit transmission across all stages of the signal path at Tone Defeat.

The patented floating design is adopted across the phono EQ, input amp and line amp stages - removing the influence of ground noise from the signal.

Symmetrical, Folding-book Circuit Design

The folding-book design for the pre-amplifier PCB mirrors the left and right signal paths for precise matching and layout.

With each channel physically identical, the C-5000 is capable of the most accurate reproduction of audio which is both wide and deep.

Further, the ground loop is minimised when other components are connected.

Dual Toroidal Transformers

Adopting independent dual toroidal transformers for the left and right channels delivers optimal separation and therefore producing a sound stage which is faithful to the original source.

Low magnetic leakage lowers adverse impact on the audio signal. Following detailed research based on trial listening, the power transformer was enclosed in a copper-plated case to suppress magnetic flux and vibration. This also assists in minimising the influence of flux in the phono circuit.

This realises a gentle, calm and even spacious sound due to enhanced reproduction of detailed signals.

Specification

		C-5000
Stereo Amplifier / Receiver
Audio Specifications	Input Terminal	RCA:6 (PHONO, TUNER, CD, LINE 1, LINE 2 IN, EXT IN), BAL:4 (PHONO, BAL 1, BAL 2, EXT IN), TRIGGER IN: 1 (Slave mode), REMOTE IN:1
	Output Terminal	RCA:3 (LINE 2 OUT, LINE 1, LINE 2), BAL:1 (BAL), TRIGGER OUT: 2 (Master mode), REMOTE OUT:1
	Rated Output Voltage	[Input 200 mV, 20 Hz-20 kHz, 0.01% THD] (BAL BYPASS) 2 Vrms / 150 ohm, (BAL ATT) 1 Vrms / 150 ohm, (LINE 1 / LINE 2) 1 Vrms / 150 ohm), (LINE 2 RECOUT) 200 mVrms / 1.2 kohm
	Maximum Output Voltage	[1 kHz, 0.05% THD] (BAL) 6 Vrms, (LINE 1 / LINE 2) 3 Vrms, (LINE 2 RECOUT) 3Vrms
	Input Sensitivity / Input Impedance	[BAL / LINEOUT: 1 V] (BAL) 200 mVrms / 52 kohm, (LINE,etc) 200 mVrms / 47 kohm, [LINE 2 RECOUT, 150mV (1 kHz) ] (PHONO MC 300 ohms) 100 uVrms / 300 ohms, (PHONO MC 100 ohm) 100 uVrms / 100 ohms, (PHONO MC 30 ohm) 100 uVrms / 30 ohm, (PHONO MC 10 ohm) 100 uVrms / 10 ohm, (PHONO MM BAL(UNBAL)) 2.5 mVrms / 52 k(47 kohm), (EXT IN) 1 Vrms / 20 kohm
	Maximum Input Signal Voltage	[LINE2 REC (1kHz, 0.05% THD)] (BAL) 2.8 Vrms, (BAL ATT) 5.6 Vrms, (LINE,etc) 2.8 Vrms,(PHONO MC) 2 mVrms, (PHONO MM) 50 mVrms, ［BAL/LINEOUT (1kHz 0.05% THD)］(EXT IN) 5.6 Vrms
	Frequency Response	[JEITA, Load 22 kohm] (BAL/LINE, etc) +0 / -3 dB (10 Hz-100 kHz), +0 / -0.3 dB (20 Hz-20 kHz)
	Total Harmonic Distortion Plus Noise	[JEITA, Input: 0.5 V] 0.0100% (BAL [LINE, etc.] to BAL [LINE], 20 Hz-20 kHz), 0.0200% (MM / MC BAL [UNBAL] to LINE 2 RECOUT, 20 Hz-20 kHz)
	Channnel Separation	[JEITA, Input 1.0 kohm terminated, 1 kHz / 10 kHz] 110 dB or higher (BAL / LINE, etc.), 80 dB or higher (MC, BAL / UNBAL), 98 dB or higher (MM, BAL / UNBAL)
	Function Separation	[IHF-A network, Input 1.0 kohm terminated, JEITA] 110 dB or higher (BAL / LINE, etc.), 75 dB or higher (MC, BAL / UNBAL), 95 dB or higher (MM, BAL / UNBAL)
	Signal-to-Noise Ratio	[IHF-A network, Input 1.0 kohm terminated, JEITA] 110 dB or higher (BAL / LINE, etc.), 80 dB or higher (MC, 300 ohms, BAL / UNBAL), 98 dB or higher (MM, BAL / UNBAL)
	Residual Noise	[IHF-A network] 3 uV (BAL / LINE OUT)
	Tone Control Characteristics	(BASS) Boost / Cut [30 Hz] ±9 dB, Turnover Frequency 350 Hz, (TREBLE) Boost / Cut [20 Hz] ±9 dB, Turnover Frequency 3.5 kHz
	Headphone Jack Rated Output Power	35 mW + 35 mW (CD, etc. [1 kHz, 32 ohm, 0.2% THD])
	Deviations from RIAA Equalizer	±0.5 dB (MC / MM BAL [UNBAL])
	Subsonic Filter	15 Hz: -3 dB (MC / MM BAL [UNBAL])
General	Power Consumption	60 W
	Standby Power Consumption	0.2 W
	Power Management (Auto Power Standby)	Yes
	Dimension (W×H×D)	435 x 142 x 451 mm; 17-1/8” x 5-5/8” x 17-3/4”
	Weight	19.1 kg; 42.11 lbs.
