MartinLogan Abyss 10 Subwoofer
Like its smaller sibling, Abyss™ 8, the Abyss 10 provides deceptively strong, yet detailed sound thanks to its 10” Hybrid Woofer System. Abyss 10 utilizes a pair of 10” passive radiators to bolster its active 10” woofer, resulting in even higher levels of output capability and deeper low frequency extension. This woofer system is driven by powerful amplification, and a precision DSP engine, all contained inside an elegant 1” thick cabinet. To complement the impressive output and speed of Abyss 10, MartinLogan engineers included a variety of connections ranging from XLR to the built-in wireless option. Abyss 10 also features MartinLogan’s powerful and intuitive control app for convenient setup and adjustment, as well as being compatible with the award-winning Anthem Room Correction (ARC®) system.
 |
Seamlessly Integrating
|
Hybrid Woofer System – The Ultimate Compact PowerhouseDespite its compact size, the aptly named Abyss 10 plays deep with surprising authority. Featuring a unique 10” Hybrid Woofer System, Abyss 10 combines an active 10” aluminum woofer with two 10” aluminum passive radiators. This innovative design offers the enhanced output of a ported subwoofer while maintaining the compact size and tight bass associated with sealed subwoofers. Enjoy the best of both worlds without compromises like larger cabinets or port noise. Abyss 10’s custom-designed aluminum woofers are engineered for peak performance using advanced Klippel analysis. The light weight, high strength, and excellent heat dissipation properties of aluminum make it ideal for delivering clean, powerful bass in such a compact design. |
|
 |
Magnitude® MT-1.6kW AmplifierTo achieve such startling levels of performance, Abyss 10’s Hybrid Woofer System is designed to handle high levels of power. Enter MartinLogan’s Magnitude MT-1.6kW amplifier, which can deliver up to 1600W peak (800W RMS) of clean power, ensuring jaw dropping impact and seamless musicality at all volume levels. MartinLogan’s Magnitude amplifiers are designed to deliver their power reserves with ultra-low distortion to ensure maximum fidelity along with high output capability. MT-1.6kW maintains precise control over Abyss 10’s woofer, guaranteeing powerful yet musical bass at all volume levels. |
Advanced Vojtko DSP Engine:
|
 |
Specifications
Specifications are subject to change without notice
|
Digital Signal Processing |
Ultra High-Resolution 500MHz Vojtko DSP Engine with 64bit processing |
|
Frequency Response |
22–120 Hz ±3 dB (Anechoic via LFE input) |
|
Low Frequency Transducer |
Triple 10" (25.4cm) Hybrid Woofer System consisting of a single high-excursion, anodized-aluminum cone in a stamped steel basket with dual anodized-aluminum cone passive radiators |
|
Cabinet |
Precision-crafted, sealed MDF enclosure featuring a robust 1-inch thick MDF structure with reinforced woofer baffles and center brace |
|
Amplifier |
Magnitude MT-1.6kW Amplifier with 1,600W peak (800W continuous) |
|
Controls (Backplate) |
Level: Interactive LED Backlit Knob |
|
Controls (via Bluetooth) |
Level: -40 to 12dB (Min-Max) |
|
Wireless Inputs |
Integrated Wireless Receiver, Wireless Transmitter Included |
|
Inputs |
Line Level: Left, Right, and LFEXLR: LFE |
|
Power Draw |
Max: 800W |
|
Feet |
Integrated Anti-Vibration Feet (carpet spikes included) |
|
Weight |
55.6 lbs (25.2 kg) |
|
Dimensions (H x W x D) |
15.4" x 15" x 15" (39.1cm x 38cm x 38cm) |
|
Finish |
Gloss Black |
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
