Cornered Audio LS1 On-wall Speaker
Taxes included.
Shipping calculated at checkout.
Standard delivery within 2–5 business days
Cornered Audio LS1 On-wall Speaker - pair
Features:
- 6 1/2" woofer with neo magnet
- 2x1" horn loaded dome tweeter
- Aluminium cabinet
- Designed for high SPL applications
- Get it in black, white or aluminium
AESTHETIC LINE SOURCE
LS1 is a very compact speaker designed to be flown horizontally in compact Line Source applications. Flying up to 6 pcs per side, the LS1 speakers are designed for medium to high SPL applications in Theatres, Hotel Lobbies, Conference rooms and high SPL entertainment venues. Flying 2 boxes will give a coverage of 90×50 degree, 4 boxes 90×40 degree and 6 boxes 90×30 degree. An array of 2×6 pieces will deliver 105 dB in 30 meters in pure hi-fi sound quality.
Our Line Source speakers weigh less than 7 kg per speaker and offer very high SPL-to-weight and SPL-to-size ratio. Drive units in the LS1 have been designed by the finest European manufacturers. The 6 1/2″ woofer of our Line Source speaker system features a strong neodymium magnet with state-of-the art-cooling and less than 1,8 dB power compression after 8 hours of maximum SPL.
The closely spaced 1″ horn-loaded dome tweeter in the LS1 offers excellent sensitivity and combines the output of a horn-loaded design with the clarity of a dome tweeter. The extruded aluminium cabinet is well dampened and the triangular shape minimises standing waves inside the cabinet. LS1 speakers offer quality sound reproduction for applications where top performance is a must.
Specifications
Power handling, IEC268: 250 watt
Power handling, peak: 1000 watt
Sensitivity, 2,83V/1m: 92 dB
Maximum SPL, long term: 116 dB
Maximum SPL, peak: 122 dB
Frequency response: 70-20.000 Hz
Nominal impedance: 8 ohm
Weight: 6,4 kg
Measurement: 502x232x167mm
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
