Isotek EVO3 SIGMAS
(Includes Premier C19 power cable)
One of the most cost-effective upgrades you can buy for any high-quality audio system, Sigmas is a multi-award-winning six-way mains conditioner featuring two high-current outlets that utilizes a lighter version of the Titan’s Direct-Coupled© circuit to provide high current low impedance power for amplifiers, subwoofers, or active loudspeakers. The four remaining output sockets are medium-current for source components. Each outlet of Sigmas has its own dedicated power cleaning network; thus, six power cleaners in one box! Sigmas represents an extremely cost-effective way to fully upgrade a complete high-end audio system.
FEATURES:
- Suitable for all audio or AV systems
- RFI reduction 75dB
- 6 optimised power cleaning circuits remove Common and Differential Mode mains noise
- 4 independent outlets for source components (10A max each)
- 2 independent high current outlets for power amps, subwoofers, active speakers etc.. (16A max each)
- 108’000A instantaneous protection
- Fully star-earthed network
- Solid core Ohno Continuous Cast copper silver-plated internal wiring with FEP virtual air dielectric.
- Supplied with IsoTek’s award winning EVO3 PREMIER POWER CABLE
- UK, EU, US, AU & CH outlets available.
- (Includes Premier C19 power cable)
SPECIFICATIONS:
| NUMBER OF OUTLETS | 6 |
| TYPE OF OUTLETS | UK, EU, US, AU & CH |
| DISPLAY | Voltage / THD / off |
| MAINS INLET | 16A IEC C20 |
| MAINS VOLTAGE | 100-240V / 50-60Hz |
| MEDIUM CURRENT | 230V x4 (10A 2'300W total) |
| MEDIUM CURRENT | 115V x4 (10A 1'150W total) |
| HIGH CURRENT | 230V x2 (16A 3'680W total) |
| HIGH CURRENT | 115V x2 (16A 1'840W total) |
| SURGE PROTECTION | 108'000A |
| DIMENSIONS | (W X H X D) 445 x 90 x 305mm |
| WEIGHT | 10Kg |
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
