Onkyo TX-RZ70 11.2-Channel AV Receiver
The TX-RZ70 is Onkyo's flagship 11.2-channel AV receiver, engineered to deliver uncompromising high-resolution audio and 8K video performance at the heart of your home theater. With 140 W per channel (8 Ω, 20 Hz–20 kHz, 0.08% THD, 2 ch driven), THX Certification, IMAX Enhanced Mode, Dirac Live room correction, and support for every major immersive audio format, the TX-RZ70 sets the benchmark for premium home cinema.
Key Features
- 11.2-Channel Amplification — 140 W/ch (8 Ω, 2 ch driven) with discrete, high-current output stages for effortless dynamic headroom.
- IMAX Enhanced Mode — Recreates IMAX content as filmmakers intended: reduced noise, brighter/clearer pictures, and a stretched aspect ratio delivering up to 26% more picture on screen.
- THX Certified — Onkyo was the first consumer brand THX-certified (1993). Four THX listening modes: Cinema, Gaming, Music, and Surround EX ensure nothing is added or removed from the source.
- Dirac Live® Room Correction — Advanced digital room correction analyses your room acoustics and applies precision filters for optimal sound at every seat.
- Dolby Atmos® / DTS:X® / Auro-3D® — Full support for all leading object-based immersive audio formats.
- 8K/60 Hz & 4K/120 Hz HDMI 2.1 — Seven HDMI inputs (three HDMI 2.1 supporting 8K/60 Hz, 4K/120 Hz, VRR, ALLM) and three HDMI outputs.
- High-Resolution Audio — Native playback of FLAC, WAV, ALAC, DSD 2.8/5.6/11.2 MHz, and Dolby TrueHD / DTS-HD Master Audio.
- Streaming & Connectivity — AirPlay 2, Chromecast built-in, Spotify Connect, TIDAL, Amazon Music HD, Deezer, TuneIn, and Bluetooth 5.0.
- Multi-Zone Output — Zone 2 and Zone 3 pre-out for whole-home audio distribution.
- Phono Input — Built-in MM phono stage for vinyl playback.
Specifications
| Specification | Detail |
|---|---|
| Channels | 11.2 |
| Power Output (8 Ω, 2 ch, 20 Hz–20 kHz, 0.08% THD) | 140 W/ch |
| Power Output (6 Ω, 1 ch, 1 kHz, 10% THD) | 185 W/ch |
| Frequency Response (Direct Mode) | 5 Hz – 100 kHz (+0/−3 dB) |
| THD+N (20 Hz–20 kHz, 8 Ω) | 0.08% |
| Signal-to-Noise Ratio (IHF-A) | 106 dB |
| Damping Factor (1 kHz, 8 Ω) | 60 |
| Input Sensitivity / Impedance (Line) | 200 mV / 47 kΩ |
| Phono Input (MM) | 2.5 mV / 47 kΩ |
| HDMI Inputs / Outputs | 7 in (3× HDMI 2.1) / 3 out (1× HDMI 2.1) |
| HDMI Video Support | 8K/60 Hz, 4K/120 Hz, HDR10, HDR10+, Dolby Vision, HLG, VRR, ALLM, eARC |
| Analog Audio Inputs | 7 (including 1 Phono MM) |
| Digital Audio Inputs | 2 Optical, 2 Coaxial |
| USB-A Port | 1 (front panel, for USB storage playback) |
| Network | Ethernet (RJ-45), Wi-Fi 5 (802.11 a/b/g/n/ac, 2.4/5 GHz) |
| Bluetooth | 5.0 (A2DP, AVRCP) |
| Streaming Services | AirPlay 2, Chromecast built-in, Spotify Connect, TIDAL, Amazon Music HD, Deezer, TuneIn |
| Surround Formats | Dolby Atmos, Dolby TrueHD, DTS:X, DTS-HD Master Audio, Auro-3D, IMAX Enhanced, THX |
| Room Correction | Dirac Live® (full bandwidth) |
| Speaker Terminals | 11 ch main + 2 ch Zone 2 (banana plug compatible) |
| Pre-Out | 11.2 ch (including 2× subwoofer), Zone 2, Zone 3 |
| Headphone Output | 1 × 6.35 mm (front panel) |
| Control | IR Remote, Onkyo Controller App (iOS/Android), RS-232C, IP Control, 12V Trigger (×2) |
| Power Consumption | 850 W (standby: 0.1 W) |
| Dimensions (W × H × D) | 435 × 185 × 493 mm |
| Weight | 19.5 kg |
| Colour | Black |
| Model Number | TX-RZ70 |
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
