Audiolab 7000A Integrated Amplifier

Nestled between the 6000 and 9000, the 7000 fuses premium traits into a pricing category that follows the mantra of class-leading performance.

Outwardly resembling the sequential series and therefore oﬀering a brand-wide visual aesthetic match, the audiolab 7000A improves on the 6000A with a genuine 70W per channel output, a new DAC, a new full-colour IPS LCD screen and more! More compact than the 9000 series, it maintains crisp ergonomics, high-quality engineering, a useful range of facilities and an excellent all-around acoustic performance and connectivity.

Classes of A and B

audiolab pulls no punches with the genuine nature of our power rating. The 7000A’s discrete Class AB power amp stage delivers 70W per channel into eight ohms, with a maximum current delivery of 9A amps into diﬃcult loads. A new standard in audiolab ampliﬁers, the output stage of the discrete power amp circuits uses a CFB (Complementary Feedback) topology, ensuring superior linearity and excellent thermal stability, as the idle current is kept independent of the temperature of the output transistors. Critically speciﬁed by Jan Ertner (lead engineer for the audiolab brand); the newly developed power supply features a substantial 250VA toroidal transformer, followed by 4x15000uF reservoir capacity (60000uF in total), helps the amp to maintain ﬁrm control of the music whilst enabling excellent dynamic range.

Name Your Source

Whatever the input source – analogue, digital, wireless or TV – the 7000A has been crafted to the same level of detail one has come to expect from audiolab, all with the latest tech to be fully equipped to cover many bases, yet it maintains a price point that keeps the audiolab brand at the forefront of quality home audio. Dual analogue inputs cater for CD players and line-level sources, dual Coax and SPDIF inputs expand this for the digital sources while a Bluetooth aptX receiver serves up a solution for wireless audio playback and smart devices. Following the growing trend for direct living room integration of premium audio electronics and there for more in tune as the centrepiece of your home audio system, the 7000A takes connectivity to a new dimension with a built-in Audio Return Channel (ARC) connection for use with screens – thus bringing the audiolab dynamic to TV-app based music playback and home theatre. And let’s not forget the direct-to-PC connection via USB.

Improved Interface

As the engineers in the audiolab camp have learned with every model and series; greatness can be improved upon. Taking the 6000A as the standard, audiolab know that the regular audio enthusiast’s thirst for speciﬁcation and features would mean that the eagerly anticipated linear upgrade from the 6000A would instinctively also oﬀer an improved display and general user interface (GUI); hence the vibrant and visually informative 2.8″ (48 x 64mm) IPS display. The detailed but simple-to-use GUI also carries through a general theme of information and structure from the 9000A, just in a more compact style. The GUI includes settings for the digital phase lock loop of the D/C converter

Specifications:

General Description	Integrated Amplifier
Design Philosophy and Core Technology	- 2 x 70W (8 ohms) / 2 x 110W (4 ohms) Class AB
	- ES9038Q2M 32-bit DAC
	- 2.8" (480x640mm) Full View IPS LCD
	- Built in Certified Hardware MQA Full Decoder (PC USB, Coax / Optical)
	- Bluetooth 5.0 (aptX / aptX LL) Support
	- Low Noise Moving Magnet Phono Stage
	- Dedicated Current-Feedback Headphone amp
	- Integrated / PRE-POWER / PRE only Modes
	- VU Digital / VU Analogue Meter
	- USB Upgrade Support
Inputs	3 x Analogue, 1 x Phono (MM), 1 x Power Amplifier,
	2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x HDMI ARC,
	1 x PC USB (USB B), 1 x Bluetooth (aptX/aptX LL), 1 x 12V Trigger
Outputs	1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger
Sampling Frequency	Optical / Coaxial: 44.1kHz - 192kHz;
	PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD512
Preamplifier Section
Gain	+6dB (Line); +55dB (Phono MM)
Input Sensitivity	820mV (Line, Volume = 0dB); 3.1mV (Phone MM, Volume = 0dB)
Input Impedance	10K (Line); 47K // 100pF (Phono MM)
Total Harmonic Distortion (THD)	< 0.0005% (1kHz @ 2V, Volume = 0dB)
Frequency Response	20Hz-20kHz (+/-0.1dB)
Output Voltage	2.3V max. (Volume = 0dB)
Output Impedance	100 ohms
Signal-to-Noise Ratio	> 110dB (Line, A-weighted); > 76dB (Phono MM, A-weighted

Caring for your Speakers and Amplifiers

To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.

Speakers

Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
Speaker cabinets cannot be replaced please handle with care.

AV & Stereo Amplifiers

If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
Turn off the amplifier before swoping out or adding speaker cable
Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
