Denon PMA-1700NE Integrated Amplifier
R 42,790.00
Taxes included.
Shipping calculated at checkout.
Standard delivery within 2–5 business days
Product Description
Product Description
Care
Care
Shipping & Returns
Shipping & Returns
Denon PMA-1700NE Integrated Amplifier
Featuring advanced ultra-high current single push-pull circuit power, Advanced AL32 Processing, and MM/MC phono equalizer, the Denon PMA-1700NE integrated amplifier delivers extraordinary sound quality with precise detail.
- Stereo amplifier
- 70W per channel (8 ohms)
- AL32 Processing
- USB-DAC
- Precise electrical controls
- MM/MC phono
| Advanced ultra-high current (UHC) single push-pull amplifier | Wide bandwidth captures everything from deep bass to detailed highs. The UHC design ensures drivability of a wide range of speaker types and impedances. |
| Hi-Res Audio certified | Able to decode high-resolution audio ALAC, FLAC, and WAV lossless files up to 24-bit/192 kHz, as well as DSD 2.8MHz and 5.6MHz tracks (the audiophile format of SACD), PMA-1700NE lets you enjoy each note exactly as the artist intended. |
| Advanced AL32 Processing Plus | Advanced AL32 Processing Plus uses data interpolation algorithms, which support high-resolution 384 kHz/32-bit audio sources. The algorithms add in the points that should exist before and after large quantities of data, smoothing out the waveform and restoring information that was lost during the digital recording. The resulting playback is highly detailed, free of interferences, richly expressive in the lower range, and beautifully faithful to the original sound. Hear your favorites like never before. |
| Built-in phono equalizer | Denon is well known for high-quality vinyl playback. The built-in phono equalizer allows direct connection to a turntable and supports input from MM cartridges. Some models also support input from MC cartridges. |
| Digital inputs | The amplifier features optical and coaxial digital inputs supporting PCM signals up to 192 kHz/24 bit to improve the sound quality of your TV audio, Blu-Rays, media players, computer, and more. |
| 110+ years of firsts in audio technology | Founded in 1910, Denon has a deep heritage of "firsts" in audio technology—from Japan's first audio electronics manufacturer to producing the world's first commercial CDs. This focused investment in audio R&D ensures you get the latest technology and highest quality with every listening experience. |
Specifications
| Amplifier Section | |
| Power Output (8 ohms, 20 Hz - 20 kHz, THD 0.07%) | 70W per channel |
| Power Output (4 ohms, 1 kHz, THD 0.7%) | 140W per channel |
| Frequency Response | 10 Hz - 100 kHz |
| Signal-to-Noise Ratio (IHF-A weighted) | 112 dB |
| Total Harmonic Distortion | 0.01% (20 Hz - 20 kHz) |
| Damping Factor | 100 (8 ohms, 1 kHz) |
| Digital Audio Section | |
| USB-DAC | Yes (USB-B input) |
| Advanced AL32 Processing Plus | Yes (384 kHz/32-bit) |
| Hi-Res Audio Support | FLAC, ALAC, WAV up to 192kHz/24-bit |
| DSD Audio Support | DSD 2.8MHz, 5.6MHz |
| Digital Input Sample Rate | Up to 192 kHz/24-bit |
| Phono Section | |
| MM Phono Input Sensitivity | 2.5 mV / 47 kohm |
| MC Phono Input Sensitivity | 0.3 mV / 100 ohm |
| MM Phono SNR | 86 dB |
| MC Phono SNR | 72 dB |
| Inputs | |
| Analog Audio Inputs | 5 (including MM/MC phono) |
| Digital Optical Input | 2 |
| Digital Coaxial Input | 2 |
| USB-B Input | 1 |
| Outputs | |
| Speaker Outputs | 2 pairs (A/B) |
| Pre-Out | 1 pair (RCA) |
| Headphone Output | 1 (6.3mm jack) |
| Gold-Plated Connectors | Yes |
| Features | |
| Advanced UHC Single Push-Pull Circuit | Yes |
| Source Direct Mode | Yes |
| Analog Mode | Yes |
| Tone Controls (Bass/Treble) | ± 10 dB |
| Balance Control | Yes |
| Speaker A/B Selection | Yes |
| Remote Control | Included (RC-1234) |
| Auto Power Off | Yes |
| General | |
| Power Consumption | 250W |
| Standby Consumption | 0.3W |
| Dimensions (W x H x D) | 17.1 x 4.8 x 13.4 inches (434 x 121 x 340 mm) |
| Weight | 24.3 lbs (11.0 kg) |
| Color Options | Premium Silver, Black |
| Build Quality | Premium construction with metal front panel |
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
