MA5300 2-channel solid state integrated amplifier (Single)
The smallest McIntosh solid state integrated amplifier, delivering 100 Watts per channel into 8 Ohms or 160 Watts into 4 Ohms. Priced and sold individually.
Description
Big sound in a compact package
A direct coupled design with dual-scale blue Watt meters that read power output for both 4 and 8 Ohm loads. It suits smaller spaces or a first McIntosh system.
Twelve inputs include 4 unbalanced, 1 balanced and 1 Moving Magnet phono input, plus 2 coaxial, 2 optical, USB and MCT digital inputs in the DA1 Digital Audio Module, which supports up to DSD256 and DXD 384kHz. A dealer-installed upgrade to the DA2 module is available.
- Type: Solid State
- 100 Watts x 2-Channels into 8 Ohms; 160 Watts x 2-Channels into 4 Ohms
- Power Guard®, Sentry Monitor™, Monogrammed Heatsinks™
- 12 analog and digital inputs
- Includes DA1 Digital Audio Module (optional upgrade to DA2 available)
- Supports 24-bit/192kHz and DSD256 files
- Bass and Treble tone controls
- A certified Roon Tested device
Specifications
| Model | MA5300 |
| Pack Type | Single |
| Available Colours | Black painted steel |
| Electronic Specifications | |
| FTC Power Output Rating | 100 W |
| Power Output per Channel | 100 W into 8 ohms 160 W into 4 ohms |
| Number of Channels | 2 |
| Rated Power Band | 20Hz to 20kHz |
| Total Harmonic Distortion | 0.005% |
| Dynamic Headroom | 1.8dB |
| Frequency Response +0,-0.5dB | 20Hz to 20kHz |
| Frequency Response, +0, -3dB | 10Hz to 100kHz |
| Sensitivity (Phono) | Moving Magnet: 2.5mV |
| Sensitivity High Level (Balanced / Unbalanced) | 0.5V/0.25V |
| Sensitivity (Power Amp input) | 1V |
| Signal To Noise Ratio (Phono) | Moving Magnet: 82dB |
| Signal To Noise Ratio (High Level) | 95dB |
| Signal To Noise Ratio (Power Amp input) | 110dB |
| Input Impedance (Balanced / Unbalanced) | 20K/20K |
| Damping Factor | 8 ohms: >200 4 ohms: >100 |
| Maximum Output | 8V Unbalanced |
| Connectivity | |
| Balanced Input | 1 |
| Unbalanced Input | 4 |
| Phono Input | 1 Moving Magnet (fixed loading) |
| Upgradeable Digital Audio Module | Yes: DA1 |
| Digital Coaxial Input | 2 |
| Digital Optical Input | 2 |
| Digital MCT Input | 1 |
| Digital USB Input | 1 |
| Unbalanced Variable Output | 1 |
| Headphone Output | 1/4" High Drive with Headphone Crossfeed Director (HXD®) |
| Home Theater PassThru | Yes |
| Unbalanced Analog Connector Type | Standard |
| Speaker Binding Post Type | Standard |
| Service Port | 1 |
| Digital Audio Specifications | |
| Digital-to-Analog Converter (DAC) Type | 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced |
| Digital Coaxial Input Sample Rate | 24-bit/44.1kHz to 192kHz |
| Digital Optical Input Sample Rate | 24-bit/44.1kHz to 192kHz |
| Digital MCT Input Sample Rate | 16-bit/44.1kHz (CD) DSD64 (SACD) |
| Digital USB Input Sample Rate | 32-bit/44.1kHz to 384kHz (PCM) DSD64, DSD128, DSD256, DXD352.8kHz, DXD384kHz |
| Control | |
| Tone Controls | Bass and Treble |
| Tone Bypass and Input Assign | Yes |
| RS232 Control Inputs | Yes |
| Power Control Outputs | 1 Main |
| Rear Panel Data Ports | 2 |
| Rear Panel IR Sensor Inputs | Yes |
| Input Level Match | Yes |
| General Specifications | |
| Vacuum Tube or Solid State | Solid State |
| Output Type | Direct Coupled |
| Output Meters | Yes |
| Dual Layer Chassis | Yes |
| Chassis Finish | Black painted steel |
| McIntosh Monogrammed Heatsinks™ | Yes |
| Power Requirement | 120V 50/60Hz, 2.3A |
| Standby Power Requirement | <0.25 Watts |
| Weights & Dimensions | |
| Unit Dimensions (W x H x D) | 17-1/2" (44.45cm) x 6" (15.2cm) x 18-3/4" (47.6cm) |
| Unit Weight | 38 lbs (17.2 kg) |
| Shipping Weight | 55.5 lbs (25.2 kg) |
Caring for your Speakers and Amplifiers
To Keep your equipment safe these are some best practices to note. Please be advised that this is only to reduce the risk of misuse and is not an exhaustive list.
Speakers
- Speaker terminals are marked red and black, ensure your amplifier to the speakers are wired on the same colours
- Ensure no loose speaker wire from the red touches a loose wire from the black as this will lead to a short circuit and damage either the speaker, the amplifier or both.
- Not all speakers are designed to play at max volume, kindly consider the pairing of your amplifier and speakers
- Speaker cabinets cannot be replaced please handle with care.
AV & Stereo Amplifiers
- If your amplifier has HDMI ports, ensure all devices are off before plugging in the HDMI cable
- Turn off the amplifier before swoping out or adding speaker cable
- Amplifiers generate heat, place them in a well ventilated space. if possible avoid having anything on top of the unit.
- adding a surge protector can assist with power dips which are likely to damage your devices. Isotek and Furman are industry standard.
- Dusty environments can sometimes lead to accumulation of dust in the electronic components that might affect heat regulation
