STUDIODECK
It's only natural to use the word "Studio" in the name of one of our turntables, as doing so brings together MoFi's software and hardware sides. And while it's our entry-level offering, StudioDeck produces high-caliber sound at a value price. Designed in collaboration with some of the world's finest audio designers, StudioDeck features an incredible amount of ingenuity and technology usually reserved for much more expensive products.
METICULOUS DESIGN AND EVALUATION
Advanced technology, user-friendly features, and unflappable design elements ensure phenomenal playback—ultimately bringing the sound of Mobile Fidelity's famous studio into your home.
 |
STUDIO TONEARMCustom developed and manufactured in the USA, this 10-inch straight aluminum gimbaled bearing tonearm delivers the ideal balanced of rigidity and low tracking error, so all you hear is what is in the grooves. Tweak to your heart's delight with provisions for adjustable tracking force, VTA, azimuth, and anti-skate. |
ISOLATED AC SYNCHRONOUS MOTOROur 300 RPM stepped-pulley AC motor provides excellent speed stability for pitch accuracy and rhythmic drive. The Delrin pulley has two positions for 33 1/3 and 45 RPM speed selection. Motor vibrations are kept away from the platter and stylus by using advanced dampening materials that decouple the motor from the rest of the turntable. |
 |
 |
CONSTRAINED LAYER DAMPENINGStudioDeck features an aluminum plate carefully bonded to an MDF body to add mass and eliminate tonal coloration, maintaining the true sound found on the record. |
TECHNICAL SPECIFICATIONS
| Specification | Details |
|---|---|
| Tonearm Type | 10" straight aluminum, gimbaled bearing |
| Tonearm Adjustments | Tracking force, VTA, azimuth, anti-skate |
| Overhang | 0.71" (18mm) |
| Offset Angle | 22.8° (±2° adjustable) |
| Cartridge Weight Range | 5g – 10g |
| Drive System | Belt drive with stepped-pulley system |
| Motor | 300 RPM AC Synchronous, isolated with advanced dampening |
| Speeds | 33⅓ RPM, 45 RPM (manual belt position change) |
| Platter | 3.88 lb (1.76 kg) Delrin, 0.75" thick |
| Wow & Flutter | 0.017% – 0.025% |
| Signal-to-Noise Ratio | 72dB |
| Plinth Construction | Constrained layer dampening: aluminum plate bonded to MDF body |
| Isolation Feet | Harmonic Resolution Systems (HRS) anti-vibration feet |
| Cartridge Options | None (tonearm only) or StudioTracker MM |
| Power Supply | 120V 60Hz, 220-230V 50Hz, 100V 50Hz |
| Power Consumption | < 5W |
| Dimensions | 19.69" W × 5.375" H × 14.25" D (500mm × 137mm × 362mm) |
| Weight | 19.1 lbs (8.7 kg) |
| Manufacturing | Custom designed and manufactured in the USA |
Key Features
- 33⅓ and 45 RPM belt drive turntable with stepped-pulley speed selection
- Custom design and manufactured in the USA
- 10-inch MoFi Studio Tonearm with gimbaled bearings
- 0.75-inch Delrin platter for superior damping
- Isolated 300 RPM AC synchronous motor
- Constrained layer dampening with aluminum plate bonded to MDF
- Anti-vibration feet designed by HRS
- Fully adjustable tonearm (tracking force, VTA, azimuth, anti-skate)
- Exceptional wow & flutter performance (0.017% – 0.025%)
- High signal-to-noise ratio (72dB)
