audiolab’s new 9000 Series represents a new standard in home audio for the connoisseur.
With CD still being a ‘go to’ medium for many audiophiles, the 9000CDT is a premium offering bringing digital music playback to match the beast that is the audiolab 9000A.
The 9000CDT is a dedicated CD transport that incorporates a high-end mechanism developed to suit the industry benchmarks set by audiolab performance philosophies.
| Isolation from vibration To ensure a flawless signal reaches the accompanying DAC, the coaxial output of the 9000CDT is fed from a differential line driver. The master clock is controlled by a high-accuracy crystal oscillator, enabling the digital output from both coaxial and optical sockets to exhibit vanishingly low levels of jitter (digital distortion). The low-friction loading tray, sturdy aluminium base and chassis of the 9000CDT work to tackle vibrations that are experienced due to the mechanics of a high-spin-velocity motor. Further, the transport is mounted in its own, electromagnetically shielded enclosure with a dedicated power supply. All of which contribute to the exemplary digital signal extraction, while the proven resonance reduction further improves performance and onward effect in ancillary Hi-Fi equipment and signal chains. |
 |
 |
Digital files in any format In addition to the class-leading CD playback design, the 9000CDT also offers digital music file compatibly via a dedicated USB ‘Type A’ connection, to the rear of the unit. Every significant hi-res and lossless audio format is catered for, including WAV, AAC and WMA, as well as compressed legacy MP3 formats. Sporting a 4.3” IPS LCD screen with a detailed but simple to use GUI, the 9000CDT offers a vivid representation of information including system settings, format, folder, track details and other data. |
| Model | 9000CDT |
| General Description | CD Transport and USB HDD player |
| USB Storage Device Audio Format | MP3, WMA, AAC, WAV file compatible |
| USB Storage Device File System | FAT12, FAT16 and FAT32 device compatible |
| Digital Output Amplitude | 500 +/-50mVpp |
| Output Impedance | 75Ω |
| Frequency Response | -0.01dB (20Hz-20kHz, ref.1 kHz) |
| Total Harmonic Distortion (THD) | < 0.002% |
| Sampling Rate | 44.1kHz (48kHz files can be played via the 9000CDT |
| but will be resampled to 44.1kHz) | |
| Digital Output Interface | 1 x Coaxial , 1 x Optical |
| Standby Power Consumption | < 0.5W |
| Power Requirements (according to region) | 220-240V - 50/60Hz |
| 100-120V - 50/60Hz | |
| Product Size (mm) (W x D x H) | 444 x 89 x 342 |
| Carton Size (mm) (W x D x H) | 514 x 470 x 161 |
| Net Weight | 5.74kg |
| Gross Weight | 7.6kg |
