Theater-reference Dolby Atmos® or DTS: X® sound through up to 7.2.4 channels complements 8K HDR video passthrough. Connect 5.2.4-channel speakers and Zone 2 speakers and switch between 5.2.4-ch and 5.2.2-ch + Zone 2 playback, or use 5 GHz/2.4 GHz Wi-Fi® and your voice to control music all around your home.
| Power Output Front L/R: | 215 W/Ch at 6 Ω, 1 kHz, 10%, 1 Channel Driven, 180 W/Ch at 6 Ω, 1 kHz, 1%, 1 Channel Driven, IEC |
| Dynamic Power: | 250 W (3 Ω, Front) 220 W (4 Ω, Front) 130 W (8 Ω, Front) |
| Input Sensitivity and Impedance: | 200 mV rms/47 kΩ (Line/Unbalance) 3.5 mV rms/47 kΩ (Phono MM) |
| THD+N (Total Harmonic Distortion + Noise): | 0.08% (20 Hz–20 kHz, Half Power) |
| 0.08% (20 Hz–20 kHz, Half Power) | 1 V rms/470 Ω (Subwoofer Pre-out) 200 mV rms/470 Ω (Zone 3/Height 2/Pre-/Line-out) |
| Phono Overload: | 70 mV (MM, 1 kHz, 0.5%) |
| Frequency Response: | 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode) |
| Tone Control: | ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble) |
| Signal-to-Noise Ratio: | 106 dB (IHF-A, Line) 80 dB (IHF-A, Phono) |
| Speaker Impedance: | 4 Ω–16 Ω |
| Signal Level | 1 Vp-p/75 Ω Composite Video 1 Vp-p/75 Ω Component Video (Y) 0.7 Vp-p/75 Ω Component Video (Pb/Pr) |
| Tuning Frequency Range: | FM 87.5 MHz–108 MHz AM 522/530 kHz–1,611/1,710 kHz |
| FM/AM Preset Memory: | 40 Stations |
| Power Supply: | AC 220–240 V~, 50/60 Hz |
| Power Consumption: | 870 W |
| Standby Power Consumption: | 0.15 W |
| Dimensions (W x H x D): | Dimensions (W x H x D): |
| Weight | 14.0 kg |
